Technical Specifications
General
| Item | Double Acting Actuator |
|---|---|
| O-Ring | NBR |
| Mounting | Direct |
| Size | DA32 – DA 330 |
| Piston | Die Cast Aluminum |
| Stop Bolt | Stainless Steel |
| Actuator Type | Double Acting |
| Brand | Bonomi Valves |
| Manufacturer Part | BNM-DA-PN-AC |
Materials & Construction
| Body Material | Extruded Aluminum |
|---|
Performance
| Pressure Rating | 40 to 115 psi |
|---|---|
| Temperature Range | Standard -4F to 185F, High -4F to +302F, Low -40F to 185F |
