Eaton Cutler-Hammer Lmt Switch Hd,Rotary Lvr,Side,.63 In,10A E50DR1

Limit Switch Head, Actuator Style Roller-Lever Arm, Actuator Location Side, Actuator Length 0.63 in, Contact Form Not Applicable, Amps 10, Voltage Rating 600V AC, Travel Operating Travel 5 Degrees , Reset Travel 2 Degrees , Total Travel 90 Degrees , Movement CW and CCW, Operating Force 2.2 N, Operating Temp. 10 Degrees to 200 Degrees F, NEMA Rating 1, 12, 13, 2, 4, 4X, 6P, IP Rating IP67, Standards CSA, RoHS, UL Listed, For Use With Mfr. No. E50SA
