Technical Specifications
General
| Orifice | 50mm |
|---|---|
| CV | 30 |
| Valve Type | 2 Way |
| Action | Pilot Diaphragm |
| De Energized State | Normally Open (NO) |
| Op Temp | Media with NBR Seal: 23°F to 176°F (-5°C to 80°C) |
| Coil Power | AC Coil: 28VA |
| Voltage Options | 12VDC |
| Voltage Tolerance | ±10% of Specified Voltage |
| Ingress Protection | IP65 |
| Insulation Class | H Class |
| Coil Duty | 100% ED (Continuous Duty) |
| Installation | No Orientation Requirement |
| Service | Liquid, Water, Air, Inert Gas |
| Brand | STC Valve |
| Manufacturer Part | STC 2DSO500F-2 |
| Size | 2″ |
Materials & Construction
| Body Material | Valve Body: 304 Stainless Steel |
|---|
Performance
| Op Pressure | AC Coil: 6 PSI to 120 PSI |
|---|
Connections
| Elec. Connection | DIN 43650, Form A |
|---|
