Technical Specifications
General
| Orifice | 20mm |
|---|---|
| CV | 7.6 |
| Valve Type | 2 Way |
| Action | Semi Direct Acting Piston |
| De Energized State | Normally Closed (NC) |
| Op Temp | Media: 23°F to 356°F (-5°C to 180°C) |
| Coil Power | Rectangular Coil (2WO250C) |
| Voltage Options | 12VDC |
| Voltage Tolerance | ±10% of Specified Voltage |
| Ingress Protection | IP65 |
| Insulation Class | H Class |
| Coil Duty | 100% ED (Continuous Duty) |
| Installation | No Orientation Requirement |
| Service | Liquid, Water, Oil, Air, Inert Gas, Steam, Vacuum |
| Brand | STC Valve |
| Manufacturer Part | 2LS200-3/4 |
| Size | 3/4″ |
Materials & Construction
| Body Material | Valve Body: 304 Stainless Steel |
|---|
Performance
| OP Pressure | AC Coil: 0 PSI to 145 PSI |
|---|
Connections
| Elec. Connection | DIN 43650, Form A (2WO250C/2W350C) |
|---|
