Technical Specifications
General
| Orifice | 4.0mm |
|---|---|
| CV | 0.6 |
| Valve Type | 2 Way |
| Action | Direct Acting |
| De Energized State | Normally Open (NO) |
| Op Temp | Media with NBR Seal: 14°F to 176°F (-10°C to 80°C) |
| Coil Power | 28-30W |
| Voltage Options | 12VDC |
| Voltage Tolerance | ±10% of Specified Voltage |
| Ingress Protection | IP65 |
| Insulation Class | H Class |
| Coil Duty | 100% ED (Continuous Duty) |
| Installation | No Orientation Requirement |
| Service | Liquid, Water, Oil, Air, Vacuum |
| Brand | STC Valve |
| Manufacturer Part | 2SO040-3/8 |
| Size | 3/8″ |
Materials & Construction
| Body Material | Valve Body: 304 Stainless Steel |
|---|
Performance
| Op Pressure | Vacuum to 60 PSI |
|---|
Connections
| Elec. Connection | DIN 43650, Form A |
|---|
