Technical Specifications
General
| Description | 3/8″ NPT Regulator (Includes Gauge & Bracket) |
|---|---|
| Filtration (Microns) | – |
| Regulating Range (PSI) | 7 to 125 |
| Metal Body | Aluminum Alloy (Epoxy Coated) |
| Plastic Bowl | Polycarbonate |
| Body Shield | Painted Steel |
| Filter | Sintered Brass (40micrometer) or Plastic (5micrometer) |
| Brand | STC Valve |
| Manufacturer Part | BR3000 |
| Size | 3/8″ |
Performance
| Flow Rate (SCFM) | 60 |
|---|---|
| Operating Temperature (°F) | 40 – 140 |
| Max. Pressure(PSI) | 150 |
Connections
| Port Size (NPT) | 3/8″ |
|---|
