Technical Specifications
General
| Metal Body |
Brass, Nickel Plated |
| Plastic Body |
PBT (Polybutylene Terephthalate) |
| Grip Ring or Collet |
300 Series Stainless Steel |
| O-Ring |
NBR (Buna-N) |
| Service |
For Air Only |
| Brand |
STC Valve |
| Manufacturer Part |
CV 5/16 N1/4 K |
| Size |
5/16″ |
Materials & Construction
| Recommended Tubing Material |
Polyurethane, Nylon, Polyethylene, Polypropylene |
Performance
| Operating Pressure Range |
0 – 180 PSI (0 – 1200 kpa) |
| Operating Temperature |
32 – 140°F (0 – 60°C) |
Connections
Download Installation & Maintenance Manual (PDF)
